Description

Available in US & EU.

Product Description

Fast Heat-up Bed: The hot bed can reach 100 degrees Celsius in about five minutes.

Ultrabase Build Surface: Enhanced Adhesion and Easily remove the print with your hands.

Technical Specifications: ● Printing Technology: FDM (Fused Deposition Modeling); ● Build Size: 220mm(L)×220(W)×250mm(H); ● Layer Resolution: ±0.1mm; ● Positioning Accuracy: X/Y/Z 0.0125/0.0125/0.002mm; ● Extruder Quantity: Single; ● Nozzle Diameter: 0.4 mm; ● Print Speed: 20~100mm/s (suggested 60mm/s); ● Supported Materials: PLA, TPU, ABS, HIPS, PETG; ● Ambient Operating Temperature: 8°C – 40°C; ● Operational Extruder Temperature: max 255°C; ● Connectivity: Trans-flash Card; USB cable(expert users only); ● Input rating: 100V/240V AC, 50/60Hz; ● output rating: 24V/15A（360W）; ● Printer Dimensions: 505mm×431mm×607mm; ● Weight: ~7kg

Easy leveling: Automatically locate the leveling spot and quickly locate the corners of the print platform during leveling.

TMC2208 stepper drivers: Silence the 3D printer. Significantly reduce the noise when printing.

Capricorn PTFE tube: Its advantages are high resistance to high temp, corrosion and ageing, as well as non-stick surface and self-lubrication.

Auto-resume from power loss: Easily continue printing from power failure or pause, saves time and filament.

Protection for hot bed wire: Reduces the damages caused by wobbling of hot bed wire during hot bed movement.

Fast heat-up bed: The hot bed can reach 100 degrees Celsius in about five minutes. Greatly improved the printing efficiency.

Double gear extrusion: Strong extruder ensures a smoother filament guiding. Compatible with flexible filaments like PLA.

Ultrabase build surface: The Ultrabase allows your prints to stick to the heated bed while the prints can be easily removed when cooling.

Parts List

Assembly instruction

Card reader

Control Box

cable

Filament

Filament holder

Memory card

Plier

Power cord

Scraper

Screws(M4)-*20 2pcs

Screws(M5)-*6 2pcs

T-nut-1PCS

Tool kit

	Photon Mono	Photon Mono X	Vyper
Printing Technology	LCD-based SLA Printing	LCD-based SLA Printing	FDM (Fused Deposition Modeling)
Build Area	130x80x165mm	192x120x245mm	245x245x260mm
Print Materials	405nm UV Resin	405nm UV Resin	PLA, ABS, HIPS, PETG, Wood and TPU
Illuminant	Matrix	Matrix	None
